Ultrasonic humidifier

首页>

基本信息型号参数产品详情功能特点工艺特色应用说明

Ultrasonic humidifier

It is widely used in textile production, printing processing, flower planting, landscape fogging, mushroom cultivation, vegetable and fruit preservation and other fields

型号参数:

型号:ZSD-10Z型号:ZSD-20Z型号:ZSD-30Z型号:ZSD-40Z型号:ZSD-50Z型号:ZSD-60Z型号:ZSD-70Z型号:ZSD-80Z型号:ZSD-90Z型号:ZSD-100Z

除湿量:

适用面积:30-360㎡

全国免费服务热线:13732203856

在线咨询

型号参数


  1. parameter name

  2. Humidification quantity

  3. Electrical source

  4. Work rate

  5. Out of the mist diameter

  6. Applicable area

  7. Adjusting range

  8. Control precision

  9. Fuselage size

  1. ZSD-10Z

  2. 3kg/h

  3. 220V~50Hz

  4. 300W

  5. 110mm(Single pipe)

  6. 30-50㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 540*320*440mm

  1. ZSD-20Z

  2. 6kg/h

  3. 220V~50Hz

  4. 600W

  5. 110mm(Single pipe)

  6. 50-80㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 540*320*440mm

  1. ZSD-30Z

  2. 9kg/h

  3. 220V~50Hz

  4. 900W

  5. 110mm(Double tube)

  6. 80-120㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 580*420*460mm

  1. ZSD-40Z

  2. 12Kg/h

  3. 220V~50Hz

  4. 1200W

  5. 110mm(Double tube)

  6. 120-150㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 580*420*460mm

  1. ZSD-50Z

  2. 15Kg/h

  3. 220V~50Hz

  4. 1500W

  5. 110mm(Three tube)

  6. 150-180㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 580*640*400mm

  1. parameter name

  2. Humidification quantity

  3. Electrical source

  4. Work rate

  5. Out of the mist diameter

  6. Applicable area

  7. Adjusting range

  8. Control precision

  9. Fuselage size

  1. ZSD-60Z

  2. 18Kg/h

  3. 220V~50Hz

  4. 1800W

  5. 110mm(Three tube)

  6. 180-220㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 580*640*400mm

  1. ZSD-70Z

  2. 21Kg/h

  3. 220V~50Hz

  4. 2100W

  5. 160mm(Double tube)

  6. 220-240㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 660*660*500mm

  1. ZSD-80Z

  2. 24Kg/h

  3. 220V~50Hz

  4. 2400W

  5. 160mm(Double tube)

  6. 240-260㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 660*660*500mm

  1. ZSD-90Z

  2. 27Kg/h

  3. 220V~50Hz

  4. 2700W

  5. 160mm(Double tube)

  6. 260-300㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 660*660*500mm

  1. ZSD-100Z

  2. 30Kg/h

  3. 220V~50Hz

  4. 3000W

  5. 160mm(Double tube)

  6. 300-360㎡

  7. 10%-99%RH

  8. ±3%RH

  9. 660*660*500mm

产品详情



功能特点


* high humidification efficiency (close to 100%), high humidification strength, small and uniform fog particles, can quickly reach the required relative humidity;


* the integrated atomization movement is equipped with a water-crossing protection device, which can effectively ensure that the atomization movement will automatically stop working when the water level is too low without additional equipment, saving costs;


* flexible and convenient control mode, automatic humidity control;


* humidity digital automatic control, the control system is equipped with imported humidity sensor, high control accuracy, quick response. Set after continuous work, no staff duty;


* after repeated tests and years of actual testing, the equipment has a compact structure and reasonable collocation. No noise when working, the liquid atomization effect is high;


* rapid and uniform humidification of large area can be realized through pipeline connection.


工艺特色


1. The integrated atomization module is adopted, the chip can be replaced, the maintenance is convenient and simple, and it can be operated on site


2. the use of stainless steel sheet metal body, elegant appearance, corrosion resistance, long life


3. equipped with high performance automatic water solenoid valve, overflow and outlet, easy to use, safe and reliable


应用说明


It is widely used in textile production, printing processing, flower planting, landscape fogging, mushroom cultivation, vegetable and fruit preservation, and other fields
