Wheel dehumidifier

首页>

基本信息型号参数产品详情功能特点工艺特色应用说明

Wheel dehumidifier

Suitable for cold storage, laboratory and other needs to adjust the humidity to less than 30%RH, and the temperature is low or too high (conventional dehumidifier can not run) environment.

型号参数:

型号:DX-200F型号:DX-600F立型号:DX-600F卧型号:DX-800F型号:DX-1000F型号:DX-1200F型号:DX-1500F型号:DX-2000F型号:DX-2500F

除湿量:0.6kg/h-15kg/h

适用面积:

全国免费服务热线:13732203856

在线咨询

型号参数


  1. Parameter name

  2. Maximum dehumidification

  3. Electrical source

  4. Most powerful

  5. Input current

  6. Parameters of

  7. Regeneration air volume

  8. Handling air diameter

  9. Regenerated air diameter

  10. Suitable temperature

  11. Fuselage size

  12. Adjusting range

  13. Control precision

  14. Heavy volume

  1. DX-200F

  2. 0.6kg/h

  3. 220V/50Hz

  4. 1.5KW

  5. 7A

  6. Φ100mm*2

  7. Φ80mm*2

  8. -10到+50℃

  9. 450*300*650mm

  10. 1%-99%RH

  11. ±1-5%

  12. 30kg

  1. DX-600F(立)

  2. 3kg/h

  3. 220V/50Hz

  4. 4.5KW

  5. 20A

  6. Φ125mm*2

  7. Φ100mm*2

  8. -10到+50℃

  9. 520*400*850mm

  10. 1%-99%RH

  11. ±1-5%

  12. 70kg

  1. DX-600F(卧)

  2. 3kg/h

  3. 220V/50Hz

  4. 4.5KW

  5. 20A

  6. Φ125mm*2

  7. Φ100mm*2

  8. -10到+50℃

  9. 886*410*500mm

  10. 1%-99%RH

  11. ±1-5%

  12. 70kg

  1. DX-800F

  2. 4.5kg/h

  3. 380V/50Hz

  4. 10KW

  5. 16A

  6. Φ200mm*2

  7. Φ150mm*2

  8. -10到+50℃

  9. 828*635*1138mm

  10. 1%-99%RH

  11. ±1-5%

  12. 150kg

  1. DX-1000F

  2. 7.5kg/h

  3. 380V/50Hz

  4. 11KW

  5. 18A

  6. Φ200mm*2

  7. Φ150mm*2

  8. -10到+50℃

  9. 828*635*1138mm

  10. 1%-99%RH

  11. ±1-5%

  12. 160kg

  1. Parameter name

  2. Maximum dehumidification

  3. Electrical source

  4. Most powerful

  5. Input current

  6. Parameters of

  7. Regeneration air volume

  8. Handling air diameter

  9. Regenerated air diameter

  10. Suitable temperature

  11. Fuselage size

  12. Adjusting range

  13. Control precision

  14. Heavy volume

  1. DX-1200F

  2. 8.5kg/h

  3. 380V/50Hz

  4. 13KW

  5. 22A

  6. Φ250mm*2

  7. Φ160mm*2

  8. -10到+50℃

  9. 880*696*1138mm

  10. 1%-99%RH

  11. ±1-5%

  12. 175kg

  1. DX-1500F

  2. 10kg/h

  3. 380V/50Hz

  4. 15KW

  5. 26A

  6. Φ250mm*2

  7. Φ160mm*2

  8. -10到+50℃

  9. 880*696*1138mm

  10. 1%-99%RH

  11. ±1-5%

  12. 180kg

  1. DX-2000F

  2. 12kg/h

  3. 380V/50Hz

  4. 18KW

  5. 36A

  6. 522*286/Φ400mm

  7. Φ200mm*2

  8. -10到+50℃

  9. 1312*856*1300mm

  10. 1%-99%RH

  11. ±1-5%

  12. 220kg

  1. DX-2500F

  2. 15kg/h

  3. 380V/50Hz

  4. 24KW

  5. 50A

  6. 522*286/Φ400mm

  7. Φ200mm*2

  8. -10到+50℃

  9. 1312*856*1300mm

  10. 1%-99%RH

  11. ±1-5%

  12. 270kg

产品详情



功能特点


* reduce air humidity quickly, easily and effectively


* the dehumidification effect is obvious in low temperature and low humidity environment


* use dynamic balance design, can be stable in the swing operation


* high performance operating core ensures effective dehumidification over a wide operating temperature range


* rotor stop/fan overload protection, leakage/temperature protection


* all-weather operation, can be -20℃, +60℃ continuous operation environment


* automatic leakage protection


* accurate humidity control, 2%-5% back difference


* equipment complies with ROHS and CE standards


工艺特色


1. The core rotor USES the Proflute rotor imported from Sweden, with a long service life and 10 years of continuous operation without fault


2. Use top international brands such as ABB, OMRON and Schneider;


3. the use of cold plate plastic spraying production, can effectively prevent the rust of the equipment, to ensure the durability and stability of the equipment


4. easy to remove the panel for quick installation and maintenance


5. International standard round flange interface


6. The air duct connection conforms to the ISO7807 standard


应用说明


Suitable for cold storage, laboratory and other needs to adjust the humidity to less than 30%RH, and the temperature is low or too high (conventional dehumidifier can not run) environment.
